Eye-C-GasSATE > HOME > Eye-C-Gas
EyeCGas infrared camera is a special equipment used to detect VOC, which can be detected for a long distance, so as to replace the high-altitude work and have good portability. It processes complex digital signals through its proprietary algorithm, and is very sensitive to the objects heat signal through the refrigeration process of the instrument itself. When a gas with a specified wavelength appears, the gas will show shadows (i.e. image) in the lens.
(1) instrument features①Designed for the industrial sector
EyeCGas is specially designed for use in the environment of toxic gas emission of petrochemical industry. The infrared gas imager is durable, well-sealed and suitable for use in outdoor industrial environment. EyeCGas meets stringent international electrotechnical commission (IEC) environmental adaptation requirements in temperature, humidity, vibration, dust and waterproofing certification.②security
EyeCGas is the only infrared gas imager with CSA essential safety certification. The essential safety level is as follows: Class 1 Div 2, which can work in the area where explosive gas exists.
③Enhanced image
Our technical experts have over 30 years of experience in infrared thermal imaging technology. EyeCGas USES appropriate enhanced thermal imaging technology to ensure the detection and localization of small gas leakage.
④Audio, video recording
EyeCGas offers real-time audio video video, improved reporting and offline analysis.
| Main performance indicators | Technical parameters |
| Detector type | High sensitivity, 320 x 240 pixels |
| Spectrum range of detector | Mid-wave infrared: 3-5 mul |
display |
3.5-inch color LCD display with resolution of 640 x 480 |
| certification | FCC 47 CFR part 15 subpart B – Radiated Emissions EN 610000-6 (Immunity to ESD, RFE, Power Frequency Magnetic field, Radiated Emissions) |
| shockproof | Mil-std 810F 514, to U.S. military specifications |
| Waterproof and dustproof | IP 65 and mil-std 810F 510.4 |
| High acceleration life test | The highest temperature: 55 ℃, the lowest temperature: - 20 ℃ |
security |
·UL1604, Electrical Equipment for use in Class I and II, Division 2, and Class III locations. ·CSA C22.2 No. 213-M1987,Non-Incendive Electrical equipment for use in Class I Division 2 Hazardous Locations ·ANSI/ISA-12.12.01 – Nonincendive Electrical Equipment for Use in Class I and II, Division 2, and Class III Hazardous (Classified) Locations Atex II 3G Ex nL IIC T6 |
| Detectable gaseous material |
Benzene, butane, ethane, ethane, ethyl ketone, 2-butanone, epoxide, heptane, hexane, isobutylene, isoprene, isoprene, isoprene, methane, methanol, octane, pentane, proaldehyde, propane, propylene, pentene, propylene oxide, styrene, toluene, xylene, methyl ethyl ketone |
